Cheap Price Cat 306E Excavator 6 Ton Popular Used Second Crawwler Excavator 5-6 Ton operating Weight
There is also a discount for face-to-face or telephone consultation!
- Fob Price: $14,000 / Unit
- Min. Order: 1 Unit
- Bucket Capacity: 1.3 m³
- Working Hours: 365
- Brand: Caterpillar
- Shipping: Sea shipping
Remarks: Complete procedures, 1 Year for machinery warranty
The machine has been tested, after-sales service and warranty are provided.
100% direct marketing
No price difference
108 tests
No accident
One year warranty
Buy at ease
Introduce
Here are the specifications for the Caterpillar 306E CR Mini Hydraulic Excavator:
🛠️ Engine & Performance
- Engine Model: Cat® C3.3B
- Net Power: 55.4 hp (41.3 kW)
- Gross Power: 57.3 hp (42.7 kW)
- Displacement: 3.3 L
- Bore x Stroke: 94 mm x 120 mm
- Emission Standards: Meets U.S. EPA Tier 4 Final/EU Stage IV
⚖️ Dimensions & Weight
- Operating Weight: 6,670 kg (14,700 lbs)
- Transport Length: 5.9 m (19.4 ft)
- Transport Width: 2.3 m (7.5 ft)
- Transport Height: 2.6 m (8.5 ft)
- Track Width: 400 mm (16 in)
- Ground Clearance: 335 mm (13.2 in)
🏗️ Digging & Lifting Capacities
- Maximum Digging Depth: 4.5 m (14.8 ft)
- Maximum Reach at Ground Level: 6.6 m (21.7 ft)
- Maximum Dump Height: 2.8 m (9.2 ft)
- Maximum Blade Depth: 0.5 m (1.6 ft)
- Tear-Out Force: 45.8 kN (10,300 lbf)
🔧 Hydraulic System
- Main System Pressure: 25,000 kPa (3,625 psi)
- Hydraulic Pump Flow: 120 L/min (31.7 gal/min)
- Auxiliary Hydraulic Lines: Standard equipment
- Optional Equipment: Hydraulic thumb, augers, hammers
🚧 Undercarriage & Travel
- Travel Speed – High: 5.5 km/h (3.4 mph)
- Travel Speed – Low: 2.9 km/h (1.8 mph)
- Maximum Traction Force – High Speed: 45.6 kN (10,260 lbf)
- Maximum Traction Force – Low Speed: 58.9 kN (13,250 lbf)
- Gradeability: 30°
- Ground Pressure: 35.5 kPa (5.1 psi)
🛢️ Service Refill Capacities
- Fuel Tank: 110 L (29.1 gal)
- Cooling System: 10.5 L (2.8 gal)
- Engine Oil: 9.3 L (2.5 gal)
- Hydraulic Tank: 80 L (21.1 gal)
🧰 Optional Features
- Auxiliary Hydraulic Lines: For various attachments
- Hydraulic Thumb: For handling large materials
- Blade: Optional with 2.3 m (7.5 ft) width
- Rubber or Steel Tracks: Suitable for different ground conditions
The Caterpillar 306E CR offers excellent digging and lifting capacities for its size, making it an ideal choice for urban construction, utility work, and other projects requiring compact machines with a high level of performance. Let me know if you need more specific details!
